> Max. 30 fps@1080p

> CVI/CVBS/AHD/TVI switchable

> 3.6 mm fixed lens (2.8 mm, 6 mm optional)

> Max. IR length 20 m, Smart IR

> 12 VDC



System overview

The Cooper Series offers simple and highly cost-effective HDCVI
solutions. It provides 24/7 reliable monitoring with high-quality image
performance, saving cost on both material and labor force. It is also
designed and built to the specific standards of Dahua.

Functions

Smart IR Illumination
With its IR illumination, the camera provides optimal performance in low
light conditions, ensuring uniformity in the brightness of B/W images.
Through its smart IR technology, the camera also compensates for the
distance of targets by adjusting the intensity of its IR LEDs, preventing
overexposure of images as targets move closer to the camera.

Multi-language OSD

The OSD offers multiple functions to meet the many requirements of
a monitoring scene, such as backlight mode, day/night mode, white
balance, privacy mask, and motion detection. 11 languages are available
for OSD: Chinese, English, French, German, Spanish, Portuguese, Italian,
Japanese, Korean, Russian and Polish.
Simplicity
HDCVI technology inherits the simplicity of traditional analog
surveillance systems, making it a great mechanism for protecting your
valuables. HDCVI can be upgraded from the traditional analog system
without replacing the existing coaxial cabling. Its plug and play design
enables it to produce high-definition videos during surveillance without
the hassle of configuring a network.

Ordering Information

Type Part Number Description
2MP Camera
DH-HAC-T1A21P 2MP HDCVI IR Eyeball Camera, PAL
DH-HAC-T1A21N 2MP HDCVI IR Eyeball Camera, NTSC

Accessories

(Optional)
PFA135 Junction Box
PFA135+PFA152-E Pole Mount Bracket
PFB205W Wall Mount Bracket
PFA106+PFB220C Ceiling Mount Bracket
PFM800-E Passive HDCVI Balun
PFM321D 12V 1A Power Adapter
PFM904 Integrated Mount Tester
